Description

The StarFish 452F PRO is a towed sidescan sonar system designed specifically for shallow water survey, Search and Rescue (SAR), and small vessel deployment. It offers high-resolution imaging with simple deployment and operation, perfect for both professional and first-time users.

Key Features

• 450kHz CHIRP Technology
  Delivers high-resolution imagery and better range performance.

• Up to 200m Swathe Coverage (100m per channel)
  Wide area coverage ideal for rapid scanning and efficient surveys.

• Stable Full-Length Tri-Fin Design
  Ensures smooth towing and image stability, even in challenging waters.

• Single Tow Cable Operation
  Simplifies deployment and minimizes drag; no need for complicated rigging.

• Simple, Intuitive Operator Software
  Plug-and-play software interface for fast startup and easy control.

• Single-Person Deployment
  Lightweight and compact — perfect for small teams or rapid-response tasks.

Technical Specifications

Top Box Specifications

| Power Supply | 90–264VAC (47–63Hz) or 9–28VDC |
| Power Consumption | 6W (500mA @ 12VDC) |
| Power Interface | 2.1mm DC jack socket |
| PC Interface | USB 2.0 B-Type connector |
| Sonar Interface | 6-way Souriau “UTS” female socket |
| Top Box Dimensions | 166mm x 106mm x 34mm |
| Top Box Weight | 0.4kg |
| Temperature Range | -5°C to +40°C |
| IP Rating | IP50 |

Best Use Cases

• Shallow Water Hydrographic Survey

• Search and Rescue (SAR) Operations

• Maritime Archaeology

• Environmental Monitoring

• Harbor and Inland Waterway Inspection
